Highlights
✦ Newly Version: The 2C53T is an upgraded version of the 2C23T, which improves the measuring range and adds math operation，cursor measurement，persistence mode，XY mode features.
✦ 2 Channel Oscilloscope: 50 MHz bandwidth, 250MSa/s sampling rate, 1Kpts record depth, automatic measurement function, max voltage 400V, vertical sensitivity 10mV/div-10V/div , support waveform image storage and export.
✦ 4.5-Digit 20000 Counts Multimeter: AC Voltage: 0-750V, DC Voltage: 0-999.9V, DC/AC Current: 0-9.999A, Resistance: 0-19.99MΩ, Capacitance: 0-99.99mF, Continuity Measurement. Multi-function meter for professionals, schools and hobbyists.
✦ Signal Generator: The maximum waveform output frequency can reach 50kHz and a step of 1Hz, and can output 13 waveforms.
✦ Save function: one-click save, screening function. You can upload the saved image by connecting to PC via Type-C. You can easily compare the waveforms by displaying the reference waveform and the measured waveform on the same screen.
✦ Excellent Design: The Oscilloscope adopts FPGA + MCU + ADC hardware architecture, built-in high-voltage protection module, adopts 2.8 inch LCD display, built-in 3000mAh Li-ion battery, standby time up to 6H, Type-C interface supports 5V/1A charging.
FNIRSI-2C53T is a versatile and highly practical three-in-one dual-channel digital oscilloscope launched by FNIRSI, designed for professionals in the maintenance and research industries. This device combines the functionalities of an oscilloscope, a multimeter, and a signal generator. The oscilloscope uses FPGA + ARM + ADC hardware architecture, featuring a 250MS/s sampling rate, a 50MHz analog bandwidth, and an integrated high-voltage protection module that supports peak voltage measurements up to ±400V. It also supports waveform screenshot saving and viewing for secondary analysis.
The multimeter function offers 4.5 digits with 19999 counts true RMS, supporting AC/DC voltage and current measurements, as well as capacitance, resistance, diode, and continuity measurements, making it an ideal multifunctional instrument for professionals, factories, schools, enthusiasts, or home use.
The built-in DDS function signal generator can output 13 types of function signals, with a maximum output frequency of 50KHz and a step size of 1Hz. The output frequency, amplitude, and duty cycle are adjustable. It features a 2.8-inch 320*240 resolution high-definition LCD screen and a built-in 3000mAh rechargeable lithium battery with a standby time of up to 6 hours. Its compact size provides users with more powerful practical functions and excellent portability.
The multimeter function offers 4.5 digits with 19999 counts true RMS, supporting AC/DC voltage and current measurements, as well as capacitance, resistance, diode, and continuity measurements, making it an ideal multifunctional instrument for professionals, factories, schools, enthusiasts, or home use.
The built-in DDS function signal generator can output 13 types of function signals, with a maximum output frequency of 50KHz and a step size of 1Hz. The output frequency, amplitude, and duty cycle are adjustable. It features a 2.8-inch 320*240 resolution high-definition LCD screen and a built-in 3000mAh rechargeable lithium battery with a standby time of up to 6 hours. Its compact size provides users with more powerful practical functions and excellent portability.
Basic Parameters:
Brand
FNIRSI
Model
2C53T
Display Screen
2.8 inch HD color screen
Resolution ratio
320*240
Charging Specifications
TYPE-C (5V/1A)
Battery
3000mAh lithium battery
Support Functions
Oscilloscope, Signal generator, Multimeter (view functional parameters for details)
Standby Time
6h (laboratory theoretical maximum)
Language
Chinese and English
Product Volume
167*89*35mm
Weight
300g
Oscilloscope Parameters:
Channel
Dual channel
Sample Rate
250MS/s
Analog Bandwidth
50M(dual channel independent 50M)
Storage Depth
1Kpts
Impedance
1MΩ
Time Base Range
10ns-20s
Vertical Sensitivity
10mV/div-10V/div (x1)
Maximum Measured Voltage
±400V
Trigger Mode
AUTO/Normal/Single
Trigger Type
Rising edge, Falling edge
Display Mode
Y-T/Rolling/X-Y
Coupling Method
AC/DC
Persistence
OFF, 500ms, 1s, ∞
Math
8 Basic Operations + FFT
Waveform Screenshot Save
Supported
Export Waveform Image
Supported
Cursor Measurement
Supported
Infinite Afterglow
Supported
Function Signal Generator Parameters:
13 Signal Waveforms
Output waveform: sine wave, rectangular wave, sawtooth wave, half wave, full wave, positive step wave, reverse step wave, exponential rise, exponential fall, DC, multi-audio, Sinker pulse, Lorentz wave
Output Frequency
0-50KHz
Output Amplitude
0-3V
Output Duty Cycle
0-100%
Multimeter Parameters:
DC Voltage
1.9999V / 19.999V / 199.99V / 1000V
AC Voltage
1.9999V / 19.999V / 199.99V / 750.0V
DC Current
19.999mA / 199.99mA / 1.9999A / 9.999A
AC Current
19.999mA / 199.99mA / 1.9999A / 9.999A
Resistance
19.999MΩ / 1.9999MΩ / 199.99KΩ / 19.999KΩ
1.9999KΩ / 199.99Ω
1.9999KΩ / 199.99Ω
Capacitance
999.9uF / 99.99uF / 9.999uF / 999.9nF / 99.99nF / 9.999nF / 9.999mF / 99.99mF
Temperature
(-55~1300℃) / (-67~2372℉)
Diode
YES
Continuity Test
YES
Standard Package:
1. 2C53T Oscilloscope *1
2. 10X P6100 Probe *1
3. Alligator Clip Probe *1
4. Multimeter Probe *1
5. Charging Cable *1
6. Storage Bag *1
7. User Manual *1
8. Packing Box *1
1. 2C53T Oscilloscope *1
2. 10X P6100 Probe *1
3. Alligator Clip Probe *1
4. Multimeter Probe *1
5. Charging Cable *1
6. Storage Bag *1
7. User Manual *1
8. Packing Box *1
Full Set Package:
1. 2C53T Oscilloscope *1
2. 10X P6100 Probe *2
3. Alligator Clip Probe *1
4. Multimeter Probe *1
5. Charging Cable *1
6. Storage Bag *1
7. User Manual *1
8. Packing Box *1
1. 2C53T Oscilloscope *1
2. 10X P6100 Probe *2
3. Alligator Clip Probe *1
4. Multimeter Probe *1
5. Charging Cable *1
6. Storage Bag *1
7. User Manual *1
8. Packing Box *1
Using Environment and Precautions
The device should be stored in a soft case, and the operating environment should be at a temperature of -5~40℃, and the relative humidity should not exceed 80%.
The device should be stored in a clean and dry place to avoid moisture, mold, heavy pressure, mechanical damage,humidity and direct sunlight.
Avoid using in the rain or fog, avoid dropping or shocking.
When the screen on the LCD does not light up, it indicates that the voltage is too low, and it needs to be charged in time.
